Ethernet acquisition card qt4140

Ethernet acquisition card qt4140

170 / 210 / 250msps 12bit Gigabit Ethernet acquisition card based on optical fiber transmission is applied in partial discharge and other aspects


Specifications

- single channel 170 / 210 / 250msps 12 bit conversion accuracy;
- integrated low pass anti aliasing filter, - 3dB bandwidth 47mhz;
- support bandwidth limiting (20MHz) function;
- 1m / 50 ohm input impedance, software programmable;
- support 6-gear programmable gain control when high resistance input;
- support 4-gear programmable gain control when input is 50 ohm;
- 1GB DDR3 memory on board;
- support external trigger input, channel trigger, soft trigger and internal pulse trigger;
- support multiple user-defined extended IO;
- one channel optical fiber output interface;
- Gigabit Ethernet supporting TCP / IP protocol with continuous transmission rate of 50mbytes / S;
- input signal protection, twice the input range;
- battery or DC power supply (optional);
- support direct connection or interconnection through router / optical switch;
